Inconel 600 Flanges Manufacturer & Supplier in India
Steel Gems supplies high-quality Inconel 600 Flanges engineered for applications that demand excellent resistance to heat, corrosion, and chemical attack. Inconel 600 is a nickel-chromium alloy known for its ability to perform reliably in extreme environments where both high temperature and corrosive media are present.
These flanges are widely used in systems exposed to oxidation and scaling at elevated temperatures, as well as in chemical processing conditions involving acidic and alkaline solutions. The alloy maintains stable mechanical properties even under continuous thermal cycling, making it suitable for critical piping connections and pressure systems.
Leading Suppliers of Inconel 600 Flanges, Providing ANSI Standard Inconel 600 Blind Flange with Tested Quality in Mumbai, India.
We offer a complete range of Inconel 600 flange types to meet different industrial needs:
- Weld Neck Flanges (Inconel 600)
- Slip-On Flanges (Inconel 600)
- Blind Flanges (Inconel 600)
- Socket Weld Flanges (Inconel 600)
- Threaded Flanges (Inconel 600)
- Lap Joint Flanges (Inconel 600)
Each flange type is engineered for specific operating conditions, ensuring suitability based on factors such as pressure rating, temperature exposure, and installation requirements. The selection of the correct Inconel 600 flange design helps achieve secure connections, leak-free performance, and long-term reliability in demanding industrial piping and process systems.
Industries We Serve - Inconel 600 and Inconel 625 Flanges
Steel Gems supplies Inconel 600 flanges for industries that operate under high-temperature and highly corrosive conditions. Inconel 600 is widely preferred in the oil and gas, petrochemical, power generation, and chemical processing industries, where equipment is continuously exposed to heat, pressure, and aggressive media.
Top Manufacturers of Inconel 600 Flanges in India, Supplying ASTM B564 & ASME B16.5 Standards Flanges with 100% Quality Assurance and Third-Party Inspection.
Steel Gems offers Inconel 600 Flanges engineered for reliable performance in high-temperature and corrosive service conditions. Made from a nickel-chromium alloy, these flanges are designed to maintain strength and stability even when exposed to continuous heat and aggressive chemical environments.
Check out latest Inconel 600 Flanges Price List
| Description | Size | Price In INR (Per Piece) |
|---|---|---|
| Inconel 600 Slip On Flange | 2 X 150# | 500.00 |
| Inconel 600 Slip On Flange | 3 X 150# | 700.00 |
| Inconel 600 Slip On Flange | 4 X 150# | 1100.00 |
| Inconel 600 Socket Weld Flange | 3/4″ X 150# X SCH XS | 300.00 |
| Inconel 600 Socket Weld Flange | 1” X 150# X SCH XS | 500.00 |
| Inconel 600 Socket Weld Flange | 1-1/2” X 150# X SCH XS | 750.00 |
| Inconel 600 Weld Neck Flange | 2 X 150# X SCH STD | 1000.00 |
| Inconel 600 Weld Neck Flange | 3 X 150# X SCH STD | 1400.00 |
| Inconel 600 Weld Neck Flange | 4 X 150# X SCH STD | 1700.00 |
| Inconel 600 Blind Flange | 3/4 X 150# | 400.00 |
| Inconel 600 Blind Flange | 1 X 150# | 700.00 |
| Inconel 600 Blind Flange | 1-1/2 X 150# | 900.00 |
Inconel 600 Pipe Flanges Specifications
| Specification Parameter | Details |
|---|---|
| ASTM/ASME Standard Materials | Cast Iron, Inconel, Mild Steel, Stainless Steel, Alloy Steel, Carbon Steel, Duplex Steel & Super Duplex Steel, Hastelloy, Copper Nickel, Wrought Iron |
| Thickness Calculation (ASME) | NPS ≤ 18 |
| Size Range | (1/2″) to (48″) |
| Manufacturing Process | Machined / Forged / Heat Treated |
| High Temperature Rating | Above 200°C (400°F) for 150 Class or above 400°C (750°F) |
| JIS Standards | 5K, 10K, 16K, 20K, 30K, 40K, 63K |
| Minimum Bore Diameter | NPS ≤ 10 |
| Dimensions Standards | ASME B16.36, DIN, AWWA C207, B16.47 Series A & B, BS1560-3.1, EN-1092, ASME B16.48, API605, BS4504, UNI, ISO, MSS SP-44, IS 2062, ISO 7005-1, API 7S-43, API 7S-15, ANSI/ASME B16.5 |
| Pressure Rating | 150 LB to 2500 LB |
| Face Types | Raised Face, Flat Face, RTJ, Lap Joint Face, Male-Female, Tongue & Groove (Small & Large) |
| Flange Types Accepted | Blind, Threaded, Lap Joint, Slip-On, Socket Weld, Weld Neck |
| Industry Applications | Power Plants, Food Processing, Waterworks Systems, Nuclear Power, Municipal Pipe Systems, Fossil Fuel Plants, Oil & Gas Industry |
| Flange Manufacturing Format | Forged / Plate / Threaded |
Looking for High-Quality Industrial Metal Products?
Get in touch with our experts for competitive pricing, fast delivery, and customized solutions.
If you are looking for Inconel 600 flange suppliers, Steel Gems is ready to help. Contact us today for more details or to get a quick quote.
Steel Gems is a trusted supplier of Inconel flanges across major industrial hubs in India, including Mumbai, Pune, Delhi, Chennai, Ahmedabad, and Hyderabad. Our supply network is structured to meet both regular and project-based requirements with consistent quality standards and reliable stock availability.
Inconel 600 Flanges Tolerance Chart
| Parameter | Tolerance Details |
|---|---|
| A – O.D. (Outside Diameter) | ≤ 24″ : ±1/16″ (1.6 mm) > 24″ : ±1/8″ (3.2 mm) |
| D – Inside Diameter (I.D.) | ≤ 10″ : ±1/32″ (0.8 mm) 12″ to 18″ : +1/8″ (3.2 mm) ≥ 20″ : -1/16″ (1.6 mm) |
| B – Diameter of Contact Face | 1/16″ RF : ±1/32″ (0.8 mm) 1/4″ RF / T&G / M&F : ±1/64″ (0.4 mm) |
| J – Hub Base Diameter | ≤ 24″ : ±1/16″ (1.6 mm) > 24″ : ±1/8″ (3.2 mm) |
| H – Hub at Welding Point | ≤ 5″ : +3/32″ (2.4 mm), -1/32″ (0.8 mm) ≥ 6″ : +5/32″ (4.0 mm), -1/32″ (0.8 mm) |
| P – Drilling | Bolt circle : ±1/16″ (1.6 mm) Bolt hole spacing : ±1/32″ (0.8 mm) |
| Bolt Circle Eccentricity | ≤ 2½” : ±1/32″ (0.8 mm) ≥ 3″ : ±1/16″ (1.6 mm) |
| C – Thickness | ≤ 18″ : ±1/8″ (3.2 mm), -0 ≥ 20″ : ±3/16″ (4.8 mm), -0 |
| K – Length of Hub | ≤ 10″ : ±1/16″ (1.6 mm) ≥ 12″ : ±1/8″ (3.2 mm) |
